Mechanical Orange Peel Grab

TECHNICAL DATA

Operation with crane, the connection type can be divided as four ropes, two ropes and single rope according to crane, it has many types, which can be designed as orange peel for stone, steel scrap, rubbish and other irregular materials, which also can be designed as clamshell for coal, sand, mine, grain, clinker and other bulk materials, also can be designed as V shape for timber.

Usage: when density of bulk material is 1.6t/m3 ,stocking angle of material should be designed as 30 degree.

Total SWL				5.0	6.3	8.0	10.0	12.5	16.0	20.0	25.0
Dead weight (Kg)	3 Ratio			2640	3120	3820	4640	5740	7520	9360	11520
	4 Ratio			2700	3190	3910	4760	5920	7760	9680	11860
	5 Ratio			2760	3260	4000	4880	6100	8000	10000	12200
Grab Capacity(m3)				1．4	1．9	2．5	3．2	4．0	5．0	6．3	8．0
No. of grab peels				6	6	6	6	6	6	6	6
Pulley		Diameter		315	355	400	450	500	560	630	630
Wire rope		Diameter		16	18	20	22	24	26	28	32
		length	3 Ratio	9．9	10．5	11．7	12．8	13．6	15．0	16．7	17．4
			4 Ratio	11．1	11．8	13．1	14．3	15．3	16．8	18．7	19．4
			5 Ratio	12．3	13．0	14．5	15．8	17．0	18．5	20．6	21．5
		Trip	3 Ratio	3660	3750	4200	4530	4950	5190	5850	6210
			4 Ratio	4880	5000	5600	6040	6600	6920	7800	8280
			5 Ratio	6100	6250	7000	7550	8250	8650	9750	10350
Overall dimensions(mm)		A		2680	2860	3250	3480	3780	4060	4620	4750
		B		2250	2420	2740	2930	3200	3440	3800	3990
		C		2290	2460	2780	2910	3160	3380	3830	4020
		D		3160	3380	3820	4060	4430	4660	5140	5480
		E		160	180	600	800	1000	1100	1280	1280
