The structure of remote control grab
Pageviews: Release Time:2017-10-11
The grab is composed by: 1.Grab Head 2.Transverse Frame 3.Through Beam 4.Press
Rods 5.Scoops 6.Control Valve Group 7.Cylinders 8.Steel Wire Rope and so on. (Refer to Pic.1-1)
①. The press rods are connected to the grab head & scoops via axis pins, and the scoops are connected to the through beam via axis pins.
②. The through beam is connected to the cylinder barrels, and the transverse frame is connected to the piston rods; the two cylinders are installed symmetrically
③. The steel wire ropes lift the transverse frame and are installed symmetrically; to increase the grab closing force via pulleys on the grab head and transverse frame.
④. The balancing stand on the transverse frame bear the lifting capacity of the grab, and for avoiding the excessive force to single rope, the two steel ropes adjust mutually.
⑤. The through beam is a box structure, wholly sealed oil tank in the middle of it, and the control valve group is installed on the cover plate of the oil tank.
