YESS01 360-degree hydraulic rotating retractable light spreader
Pageviews： Release Time：2017-10-16
YESS01 360-degree hydraulic rotating retractable light spreader is also designed for gantry crane. Dead weight is 10T，compared to12.5T of YESS, is more suitable for the transformation of the old gantry crane container. The previous 40T gantry crane can also use this YESS01 spreader. The components of this spreader are produced by the imported Sweden WELDOX700 steel, which have high strength and good weldability. This spreader is widely used in Vietnam, Hong Kong, and Hutchison Whampoa terminal.
 PARAMETER TYPE |
YESS01 360-degree hydraulic rotating retractable light spreader |
| Dead Weight | ≤10 t(Containing rotating hook) |
| SWL | 35.5 t |
| Allowable load eccentricity | Length direction1.25m, width direction 0.26m |
| Corners lug load value | N/A |
| retractable values（20’-40’） | ≤25 s |
| Guide plate（0°-180°） | 5~7 s |
| Rotating pin（0°-90°） | ≤1.2 s |
| Guide plate torque | 1200 N.m |
| Supply voltage | AC380V(3P) |
| Frequency | 50HZ or 60HZ |
| Control voltage | AC20-25V |
| Total power | 11 kw |
| Motor overload protection value | MAX 18A |
| Degree of protection | IP54 |
| Solenoid valve voltage | Upon to clients |
| Oil Pump displacement | 65 L/min |
| System work pressure | 120 bar |
| oil tank capacity | 120L~150L |
| Operating ambient temperature | -20℃-+40℃ |
| Form of rotating pin | ISO folating pin，drove by fuel tank |
| flex drive mode | hydraulic motor chain turn |
| Guide plate equipment | Hydraulic motor driven gear |
| Translation distance | ±800 mm |
| Translation speed | ≤25 s/800 mm |
| Rotating speed | 1~3r/min |
